VICI DBS Whisper Nitrogen Generator
Not sure which configuration is right for your application? Schedule a free consultation with our technical consultants today!
Schedule a consultationProduct Description
The VICI DBS Whisper series delivers a reliable, continuous supply of nitrogen gas using proprietary high-efficiency hollow fiber membrane technology. Designed for LC/MS and related analytical laboratory applications, the Whisper eliminates the need to handle high-pressure gas cylinders by generating nitrogen directly from a dry, oil-free compressed air supply already present in the lab. With a low pressure drop of just 1 barg (14.5 psig), Whisper generators can easily share an existing compressed air line. Each unit features an integrated economy mode as standard, minimal maintenance requirements, and a 2-year warranty.
- Technology: Proprietary hollow fiber membrane separation
- Air Supply Required: External dry, oil-free compressed air (1 barg / 14.5 psig pressure drop)
- Economy Mode: Integrated as standard
- Warranty: 2 years standard
Applications
LC/MS (nebulizing gas, curtain gas, shield gas, sheath gas, electrospray gas, APCI gas, jet stream gradient), NMR spectroscopy, sample evaporators, ELSD (evaporative light scattering detectors), corona & charged aerosol (CAD) detectors, solvent evaporation
Whisper Standard Models
| Part Number | Flow Rate | Purity | Max Pressure |
| DB-WN2-0-40 | 40 L/min | 97% @ 40 L/min 99% @ 20 L/min | 10 barg (160 psig) |
| DB-WN2-0-80 | 80 L/min | 97% @ 80 L/min 98% @ 50 L/min | 10 barg (160 psig) |
| DB-WN2-0-120 | 120 L/min | 95% @ 120 L/min 98% @ 50 L/min | 10 barg (160 psig) |
Whisper Hybrid Models
Hybrid models provide both high-purity nitrogen and filtered, dried air from a single unit — ideal for LC/MS systems requiring multiple gas streams simultaneously.
| Part Number | Flow Rates | Purity | Max Pressure |
| DB-WN2-0-10-HY (Whisper 0-10 Hybrid) | Curtain: 12 L/min @ 7 barg Exhaust: 10 L/min @ 4 barg Source: 26 L/min @ 7 barg | 99% | 7 barg (100 psig) |
| DB-WN2-0-40-HY (Whisper 0-40 Hybrid) | Curtain: 40 L/min @ 7 barg Exhaust: 25 L/min @ 4 barg Source: 22 L/min @ 7 barg | 97% | 7 barg (100 psig) |
| DB-WN2-0-40-HY-P-E (Whisper 0-40 Hybrid P-E Single) | Curtain & source gas streams | 99% | 7 barg (100 psig) |
| DB-WN2-0-40-HY-P-E-D (Whisper 0-40 Hybrid P-E Dual) | Curtain: 15 L/min @ 7 barg Source: 70 L/min @ 7 barg | 99% | 7 barg (100 psig) |
| DB-WN2-0-80-HY (Whisper 0-80 Hybrid) | Curtain: 80 L/min @ 7 barg Exhaust: 25 L/min @ 4 barg Source: 22 L/min @ 7 barg | 97% | 7 barg (100 psig) |
| DB-WN2-0-120-HY (Whisper 0-120 Hybrid) | Curtain: 120 L/min @ 7 barg Multiple gas streams | 95–97% | 7 barg (100 psig) |
Options available: 10 L tank, 10 m extension tubing
