Technical Specifications
Model sizes/Description | 30 | 55 | 75 | 110 | 160 | 260 | 450 | 750 | |
Stainless steel interior
|
Volume approx. l | 32 | 53 | 74 | 108 | 161 | 256 | 449 | 749 |
Width (A) mm | 400 | 560 | 640 | 1040 | |||||
Height (B) mm | 320 | 400 | 560 | 480 | 720 | 800 | 720 | 1200 | |
Depth (less 39 mm for fan) (C) mm | 250 | 330 | 400 | 500 | 600 | ||||
Max. number of grids/shelves number | 3 | 4 | 6 | 5 | 8 | 9 | 8 | 14 | |
Max. loading per grid/shelf kg | 20 | 30 | |||||||
Max. loading of chamber kg | 60 | 80 | 120 | 175 | 210 | 300 | |||
Max. loading per slide-in drip tray kg | 1,5 | 3 | 4 | 8 | |||||
Max. loading per bottom drip tray kg | 1,5 | 3 | 4 | 8 | |||||
Textured stainless
steel exterior |
Width (D) mm | 585 | 745 | 824 | 1224 | ||||
Height (size 450, 750 with castors) (E) mm | 704 | 784 | 944 | 864 | 1104 | 1183 | 1247 | 1720 | |
Depth (without door handle, depth of handle +56 mm) (F) mm | 434 | 514 | 584 | 684 | 784 | ||||
Standard
equipment |
Stainless steel grids, electropolished number | 1 | 2 | ||||||
Standard works calibration certificate (measuring point chamber center) °C | 37 | ||||||||
Temperature
|
Working temperature range °C | at least 5 (IN/INplus) 10 (IF/IFplus) above ambient temperature up to +80 | |||||||
Setting temperature range °C | 20 to 80 | ||||||||
Setting accuracy °C | 0.1 | ||||||||
Further data
|
Electrical load at 230 V, 50/60 Hz approx. W | 1600 | 1000 | 1250 | 1400 | 1600 | 1700 | 1800 | 2000 |
Electrical load at 115 V, 50/60 Hz approx. W | 800 | 900 | 1500 | 1800 | |||||
Packing data
|
Net weight approx. kg | 48 | 57 | 66 | 76 | 96 | 110 | 161 | 217 |
Gross weight (packed in carton) approx. kg | 64 | 76 | 85 | 101 | 122 | 161 | 227 | 288 | |
Width approx. mm | 660 | 730 | 830 | 930 | 1330 | ||||
Height approx. mm | 890 | 950 | 1130 | 1050 | 1300 | 1380 | 1440 | 1910 | |
Depth approx. mm | 650 | 670 | 800 | 930 | 1050 | ||||
Order No. Incubators
I = Incubator
N = Natural convection
F = Forced convection
plus = Model with TwinDISPLAY
|
IN30 | IN55 | IN75 | IN110 | IN160 | IN260 | IN450 | IN750 | |
IN30plus | IN55plus | IN75plus | IN110plus | IN160plus | IN260plus | IN450plus | IN750plus | ||
IF30 | IF55 | IF75 | IF110 | IF160 | IF260 | IF450 | IF750 | ||
IF30plus | IF55plus | IF75plus | IF110plus | IF160plus | IF260plus | IF450plus | IF750plus |
