Technical Specifications
Technical Specifications of produced water:
- Resistivity/Conductivity:
18.2 MOhm x cm | 0.055 µS/cm; Type I
- Production Rate:
max. 8 L/h
- Total Organic Carbon (TOC):
< 10 ppb (Reagent)
< 3 ppb (Analytical)
Technical Specifications |
|
---|---|
ultrapure water quality | 0.055 µS/cm; Type I |
resistivity | 18.2 MegaOhm/cm |
total organic carbon (TOC) | < 10 ppb reagent, < 3 ppb Analytical |
dispensing flow rate | 1.5 L/min |
production rate | 8 L/min* |
bacteria | < 1 cfu/mL |
particulate | > 0.2 µm less than 1 particulate/mL |
RNAse | < 1 pg/mL** |
DNAse | < 5 pg/mL** |
dimensions, weight, power | 504 x 340 x 535 mm, 16-20 kg, 110 - 230 V |
*not possible to tap pure water **with microbiological final filter |
Feed Water Requirements |
|
---|---|
type of feed water | tap water |
feed water conductivity | < 1400 µS/cm |
inlet pressure | 1.5 to 6 bar |
free chlorine | < 0.1 mg/L |
Silt Density Inded (SDI) | < 3 |
pH | 3 to 9 |
temperature | 5 to 25 °C |
