Hermle Z446 Series Centrifuge Bundles
$10,000.00 – $13,800.00
Not sure which configuration is right for your application? Schedule a free consultation with our technical consultants today!
Schedule a consultationProduct Description
- HIGH CAPACITY 4 x 750ml swing out rotor,
– Up to 68 x 15ml or 28 x 50ml - Ideal for Tissue Culture applications
- Advanced programming with automatic rotor recognition
- Available with refrigeration
Bundle Options
Z446 Ambient Tissue Culture Bundle
Z446-K Refrigerated Tissue Culture Bundle
Z446 Ambient Microplate Bundle
Z446-K Refrigerated Microplate Bundle
The Z446 universal centrifuge series offers the highest capacity of any benchtop Hermle-Benchmark model. With air-craft grade, premium alloy construction, the 4 x 750ml swing out rotor can withstand centrifugal forces upwards of 4,500 xg with full loads of up to 28 x 50ml, 68 x 15ml tubes, and up to 20 x microplates.
Advanced microprocessor controls allow for instant rotor identification,which automatically converts the rotational speed to the relevant g-force (rcf), preventing the user from setting a speed above the capabilities of the installed rotor. In addition to retrieving saved programs, the easy to use front panel can adjust accel/decel rates, and change the end of run alarm tone. Rotor exchange is simple and requires less than one minute. An included rotor wrench can be used to loosen and install all rotors. As soon as the rotor is placed on the motor shaft, the identification process activates and the installed rotor code is displayed on the backlit LCD display.
Technical Specifications
| Speed Range | : | 200 to 16,000 rpm |
| Max. RCF | : | 24,325 xg |
| Max. Capacity | : | 4 x 750ml |
| Temp. Range | : | -20°C to 40°C (Z446-K only) |
| Dimensions | : | 21.3 x 26.4 x 15.4 in. (54.1 x 67 x 39.1 cm.) 28.7 x 26.4 x 15.4 in. (-K) (72.9 x 67 x 39.1 cm.) |
| Timer | : | up to 99 hr, 59min and continuous |
| Weight | : | 174 lbs / 244 lbs (-K) |
| Electrical | : | 115V, 60Hz |
| Power (Watts) | : | 600W / 1630W (-K) |
Technical Specifications
| Speed Range | : | 200 to 13,500 rpm |
| Max. RCF | : | 17,371 xg |
| Max. Capacity | : | 24 x 1.5/2.0ml 24 x 2.0ml spin column |
| Dimensions (W x D x H) |
: | 11 x 13.8 x 9.5 in. 28 x 35 x 24 cm. |
| Timer | : | up to 99 hr, 59min and continuous |
| Weight | : | 27.6 lbs (12.5 kg) |
| Electrical | : | 120V or 230V, 50/60 Hz 170W |
Replacement Parts & Accessories
To view available parts for this instrument and instruments like it, click here.
Our parts and accessories inventory is constantly changing. Don't see what you're looking for? Give us a call, we'll be happy to help.
Service
Service Agreements |
Silver |
Gold |
First Class Ship & Fix |
Economy Ship & Fix |
| Preventative Maintenance Visit | 1 Preventative Maintenance Visit per Year | 1 Preventative Maintenance Visit per Year | ||
| Parts Covered |  |
|
||
| Labor Covered | |
|
|
|
| Unlimited Remote Tech Support | |
|
|
|
| Depot Repair | |
|
||
| Depot Preventative Maintenance | |
