Hermle Z32 HK Centrifuge
- Compact, Super Speed Centrifuge, up to 38,007 xg
- Also accepts a variety of low speed swing out rotors
- Powerful Refrigeration
- Sing Out Rotor For 8 x 50ml or 12 x 15ml
- 5-Year Factory Warranty
Not sure which configuration is right for your application? Schedule a free consultation with our technical consultants today!
Schedule a consultationProduct Description
Hermle Z32 HK Super Speed Centrifuge
The Z32 HK utilizes much of the technology of our popular Z326 series, with a larger and more powerful motor drive, providing increased speed up to 20,000 rpm (38,007 xg). With 16 available rotor options, the Z32 HK is not only ideal for high speed separations, it would also be classified as a “universal” centrifuge, offering economy angled and swinging bucket rotors for lower speed applications. Tubes from 0.2ml up to 85ml can be accepted, and rotors can quickly be exchanged without any required programming, utilizing the instant rotor identification system.
Despite an impressive capacity of up to 4 x 145ml (or 6 x 85ml), the Z32-HK is surprisingly compact. The refrigeration system is conveniently located behind the rotor chamber, resulting in narrow design of less than 16 inches wide. Advanced microprocessor controls allow for instant rotor identification, which automatically converts the rotational speed to the relevant g-force (rcf), preventing the user from setting a speed above the capabilities of the installed rotor. In addition to retrieving saved programs, the easy to use front panel can adjust accel/decel rates, and change the end of run alarm tone
Specifications
| Speed Range | : | 200 to 20,000 rpm |
| Max. RCF | : | 38,007 xg |
| Max. Capacity | : | 4 x 145ml |
| Temp. Range | : | -20°C to 40°C |
| Dimensions | : | 15.7 x 27.5 x 14.1 in. 39.9 x 69.9 x 35.8 cm. |
| Timer | : | up to 99 hr, 59min and continuous |
| Weight | : | 156 lbs (71 kg) |
| Electrical | : | 120V, 60HZ, 1200W |
Rotor Options
| Z032-HK | Z32 HK Super Speed Refrigerated Centrifuge, without rotor |
| Z306-100 | Swing Out Rotor, Economy, 4 x 145ml, (4,500rpm/3,350xg) accepts 1.5ml up to 145ml tubes, requires inserts (see pdf literature for a full listing) |
| Z326-100H | Swing Out Rotor, with hermetically sealed buckets 4 x 100ml, (5,000rpm/3,885xg) accepts 1.5ml up to 100ml tubes, requires inserts (see pdf literature for a full listing) |
| Z326-2420 | Rotor, 24 x 1.5/2.0ml with Quick-Seal lid (17,000rpm/27,460xg) |
| Z326-2420H | Rotor, 24 x 1.5/2.0ml, Hermetically Sealed (20,000rpm/38,007xg) |
| Z326-3020H | Rotor, 30 x 1.5/2.0ml, Hermetically Sealed (17,000rpm/30,368xg) |
| Z326-4420 | Rotor, 44 x 1.5/2.0ml with Quick-Seal lid (16,000rpm/24,325xg) |
| Z326-3202 | Rotor, 4 x PCR Strips (15,000rpm/15,343xg) |
| Z326-2010 | Rotor, 20 x 10ml (14,000rpm/21,472xg) |
| Z326-1050 | Rotor, 10 x 50ml conical (9,000rpm/11,770xg) |
| Z326-0650-HS | Rotor, 6 x 50ml round (16,000rpm/24,039xg) |
| Z326-0485 | Rotor, 4 x 85ml (15,000rpm/23,140xg) |
| Z326-0685-25 | Rotor, 6 x 85ml “Super rotor” Fits 85ml, 50ml, 15ml, and 7ml(13,000rpm/21,726xg) |
| Z326-1215 | Rotor, 12 x 15ml (6,000rpm/4,427xg) |
| Z326-3015 | Rotor, 30 x 15ml (4,500rpm/2,830xg) |
| Z326-0650-LS | Rotor, 6 x 50ml (6,000rpm/4,427xg) |
| Z326-02MP | Swing Out Rotor, 2 x 3 microplates (4,500rpm/2,716xg) |
| Z326-MPCA | NEW! Universal, 3 place chamber slide and 35/60mm dish adapter for microplate carriers 2/pk |
[/row]
Replacement Parts & Accessories
To view available parts for this instrument and instruments like it, click here.
Our parts and accessories inventory is constantly changing. Don't see what you're looking for? Give us a call, we'll be happy to help.
Service
Service Agreements |
Silver |
Gold |
First Class Ship & Fix |
Economy Ship & Fix |
| Preventative Maintenance Visit | 1 Preventative Maintenance Visit per Year | 1 Preventative Maintenance Visit per Year | ||
| Parts Covered |  |
|
||
| Labor Covered | |
|
|
|
| Unlimited Remote Tech Support | |
|
|
|
| Depot Repair | |
|
||
| Depot Preventative Maintenance | |
