VIP ECO Natural Refrigerant -86°C Freezer
Not sure which configuration is right for your application? Schedule a free consultation with our technical consultants today!
Schedule a consultation Have One To Sell?Product Description
Ensure optimal storage for your temperature-sensitive samples with the VIP ECO Natural Refrigerant -86°C Freezer (MDF-DU502VHA-PA). This ultra-low temperature freezer is purpose-built to meet the stringent requirements of biorepositories, pharmaceutical R&D, contract research organizations, and medical facilities. With a capacity of 18.6 cu.ft. (528 L) and energy-efficient performance down to -86°C, the VIP ECO series is designed for reliable, sustainable cold storage.
Key Features:
- Superior Cooling Performance: The MDF-DU502VHA-PA maintains temperatures as low as -86°C, ensuring the stability and integrity of critical biological materials.
- Natural Refrigerant System: Equipped with an eco-friendly cooling system, the freezer operates using natural refrigerants, reducing its environmental footprint while delivering consistent ultra-low temperature performance.
- ENERGY STAR® Certified: The VIP ECO Model MDF-DU502VHA-PA is ENERGY STAR Certified, consuming only 0.37 kWh/cu.ft. daily, resulting in significant energy savings compared to traditional ultra-low temperature freezers.
- Precise Temperature Control: Engineered for temperature uniformity, the freezer provides unmatched stability for long-term storage, even under demanding conditions.
- Robust Alarm & Monitoring Systems: Advanced control and alarm configurations ensure continuous monitoring of internal conditions, with multiple fail-safe mechanisms to protect valuable samples.
Applications:
This freezer is ideal for storing:
- Temperature-sensitive samples, including therapeutics and biospecimens.
- Viable samples, such as stem cells, genetically engineered tissues, and vaccines.
- Critical research materials, including CAR-T and CAR-NK cells.
- Valuable pharmaceuticals, clinical trial samples, and pathogenic samples for high-security labs.
Quick Specifications:
- Capacity: 18.6 cu.ft. (528 L)
- Cooling Performance: Down to -86°C
- Energy Consumption: 0.37 kWh/cu.ft. daily
- Certifications: ENERGY STAR Certified (Unique ID 2330321)
- Temperature Range: -50°C to -86°C
Built for Sustainability:
The VIP ECO series prioritizes energy efficiency and environmental responsibility without compromising on performance. By utilizing natural refrigerants and achieving ENERGY STAR certification, it ensures a reduced environmental impact while maintaining reliable long-term storage solutions for critical biological samples.
Specifications:
| ELECTRICAL | 115V |
|---|---|
| EXTERNAL DIMENSIONS | 31.1″ W x 34.7″ D x 78.5″ H (790 x 882 x 1993 mm) |
| INTERNAL DIMENSIONS | 24.8″ W x 23.6″ D x 55.1″ H (630 x 600 x 1400 mm) |
| EFFECTIVE CAPACITY | 18.6 cu.ft. (528 L) |
| INTERNAL DOORS | 2 (insulated, ABS, stainless steel frames, positive latches) |
| INSULATION | Foamed-in-place and VIP Plus vacuum insulated panels: 3.1 in (80 mm) |
| SHELVES | 3 shelves (adjustable); Inner dimensions: 24.2″ W x 21.0″ D (615 x 534 mm); Load: 110 lbs. (50 kg) per shelf |
| ACCESS PORT | 3; upper back wall (back-up system), bottom left (recorder sensor), bottom right (access); Inner diameter: 0.6 in (17 mm) |
| NET WEIGHT | 542 lbs (246 kg) |
| COMPRESSOR | (2) 750 W, variable speed |
| REFRIGERANT | High-stage R-290 natural refrigerant, Low-stage R-170 natural refrigerant |
| TEMPERATURE CONTROL RANGE | -50°C to -86°C in 1° increments |
| ALARMS | Power failure, high temperature, low temperature, sensor failure, filter alarm, door ajar, remote alarm, battery life, fan motor life, fan lock, cooling circuit abnormality |
| COOLING PERFORMANCE | -86°C center of chamber |
| TEMPERATURE CONTROL SYSTEM | Microprocessor, LCD color touchscreen data entry, password protected |
| AREA FOOTPRINT | 7.49 ft (0.70 m) |
| DATA MANAGEMENT | Optional with LabAlert® Monitoring System |
| SOUND LEVEL | 46 dB[A] (background noise 20 dB[A]) |
| STORAGE (BOXES) FOR 2”/51 MM FIBERBOARD BOXES | 384 |
| STORAGE (RACKS) FOR 2”/51 MM FIBERBOARD BOXES | 16 |
| STORAGE (BOXES) FOR 3”/76 MM FIBERBOARD BOXES | 256 |
| STORAGE (RACKS) FOR 3”/76 MM FIBERBOARD BOXES | 16 |
| ENERGY STAR CERTIFIED | ENERGY STAR Unique ID 2330321 |
Why Choose GMI Certified Pre-Owned?
At GMI, we ensure that our Certified Pre-Owned VIP ECO Freezers are refurbished by factory-trained engineers to meet OEM specifications. With a full warranty, extended service options, and significant savings, you can trust that your investment is protected and performing at its peak.
Contact Us
Upgrade your cold chain storage with the VIP ECO Natural Refrigerant -86°C Freezer (MDF-DU502VHA-PA) from GMI today, and ensure the safe, energy-efficient preservation of your lab’s most critical materials.
