(1) Centrifuge, (1) Horizontal Rotor, (4) Buckets, (4) Adapters 5 mL conical, (4) Bio-containment Lids
Hettich Universal 320 | 320R Benchtop Centrifuge
$5,560.00 – $9,425.00
Not sure which configuration is right for your application? Schedule a free consultation with our technical consultants today!
Schedule a consultationProduct Description
Max. Capacity
4 x 200 mL / 6 x 94 mL
Max. RPM/RCF
15,000/21,382
Temperature Control
-20 to +40ºC (320 R)
BLOOD | CELL CULTURE | URINE | CYTOLOGY | PLATES
Five Year Warranty
Quiet Operation
Functional Design
Enhanced Safety
Technical Specifications
| Model | UNIVERSAL 320 |
UNIVERSAL 320 R
|
| Max. Capacity | 4 x 200 ml / 6 x 94 ml |
4 x 200 ml / 6 x 94 ml
|
| Max. RPM/RCF | 15,000/21,382 | 15,000/21,382 |
| Temp. Control | Ambient |
-20 °C to +40 °C
|
| Dims. (HxWxD) mm | 346 x 401 x 529 |
346 x 407 x 698
|
| Dims. (HxWxD) in | 14 x 16 x 20.5 | 19 x 16 x 27 |
| Weight (kg) | 31 | 52 |
| Weight (lbs) | 68 | 117 |
| Power Supply | 120 V | 120 V |
| Warranty | 5-years | 5-years |
| Rotor Type(s) | Swing-out, Fixed-angle, Cytology, Hematocrit |
Swing-out, Fixed-angle, Cytology, Plates
|
Packages
UNIVERSAL 320 | 320R Application Packages
BLOOD | CELL CULTURE | URINE | CYTOLOGY | PLATES
UNIVERSAL 320 / 320R – CONICAL TUBE PACKAGE – 5 ML – BC
4170-10-0222 | 4170-10-0231
The UNIVERSAL 320 Conical Tube Package comes complete with everything you need to perform your application. This includes the UNIVERSAL 320 or UNIVERSAL 320 R centrifuge, swing-out rotor, buckets, adapters for 5 mL conical tubes and bio-containment lids. Many a-la-carte options are also available, contact us for more details.
PACKAGE CONTENTS
| TUBE QTY. | VOLUME (mL) | SIZE (mm) | RPM | RCF |
| 16 | 5 (Conical) | 17 x 59 | ≤ 4,500 | ≤ 3,328 |
UNIVERSAL 320 / 320R – BLOOD TUBE PACKAGE
4170-10-0053 | 4170-10-0062
The UNIVERSAL 320 Blood Package comes complete with everything you need to perform your application. This includes the UNIVERSAL 320 or UNIVERSAL 320 R centrifuge, swing-out rotor, buckets and adapters for for 13 x 75/100 and 16 x 75/100 mm tubes. Many a-la-carte options are also available, contact us for more details.
PACKAGE CONTENTS
(1) Centrifuge, (1) Horizontal Rotor, (4) Buckets, (4) Adapters 13 x 75/100 mm, (4) Adapters 16 x 75/100 mm
| TUBE QTY. | VOLUME (mL) | SIZE (mm) | RPM | RCF |
| 28 | 1.6 – 7 | 13 x 75/100 | ≤ 5,000 | ≤ 3,913 |
| 28 | 4 – 10 | 16 x 75/100 | ≤ 5,000 | ≤ 3,913 |
UNIVERSAL 320 / 320R – BLOOD TUBE PACKAGE – 4 – BC
4170-10-0224 | 4170-10-0233
The UNIVERSAL 320 Blood Tube Package 4 BC comes complete with everything you need to perform your application. This includes the UNIVERSAL 320 or UNIVERSAL 320 R centrifuge, swing-out rotor, buckets and adapters for 13 x 75/100 and 16 x 75/100 mm tubes. Many a-la-carte options are also available, contact us for more details.
PACKAGE CONTENTS
(1) Centrifuge, (1) Horizontal Rotor, (4) Buckets, (4) Adapters 13 x 75/100 mm, (4) Adapters 16 x 75/100 mm, (4) Bio-containment lids
| TUBE QTY. | VOLUME (mL) | SIZE (mm) | RPM | RCF |
| 28 | 1.6 – 7 | 13 x 75/100 | ≤ 4,500 | ≤ 3,215 |
| 20 | 4 – 10 | 16 x 75/100 | ≤ 4,500 | ≤ 3,215 |
UNIVERSAL 320 / 320R – URINALYSIS PACKAGE
4170-10-0066 | 4170-10-0065
The UNIVERSAL 320 Urinalysis Package comes complete with everything you need to perform your application. This includes the UNIVERSAL 320 or UNIVERSAL 320 R centrifuge, swing-out rotor, buckets, and adapters for KOVA tubes. Many a-la-carte options are also available, contact us for more details.
PACKAGE CONTENTS
(1) Centrifuge, (1) Horizontal Rotor, (4) Buckets, (4) Adapters KOVA
| TUBE QTY. | VOLUME (mL) | SIZE (mm) | RPM | RCF |
| 12 | 12 – KOVA | 17 x 102 | ≤ 4,500 | ≤ 3,102 |
UNIVERSAL 320 / 320R – CELL CULTURE PACKAGE – 4
4170-10-0054 | 4170-10-0063
The UNIVERSAL 320 Cell Culture Package 4 comes complete with everything you need to perform your application. This includes the UNIVERSAL 320 or UNIVERSAL 320 R centrifuge, swing-out rotor, buckets and adapters for 15 and 50 mL tubes. Many a-la-carte options are also available, contact us for more details.
PACKAGE CONTENTS
(1) Centrifuge, (1) Horizontal Rotor, (4) Buckets, (4) Adapters 15 mL, (4) Adapters 50 mL
| TUBE QTY. | VOLUME (mL) | SIZE (mm) | RPM | RCF |
| 16 | 15 Conical | 17 x 120 | ≤ 4,500 | ≤ 3,305 |
| 4 | 50 Conical | 29 x 115 | ≤ 4,500 | ≤ 3,260 |
UNIVERSAL 320 / 320R – CELL CULTURE PACKAGE – 4 – BC
4170-10-0205 | 4170-10-0234
The UNIVERSAL 320 Cell Culture Package 4 BC comes complete with everything you need to perform your application. This includes the UNIVERSAL 320 or UNIVERSAL 320 R centrifuge, swing-out rotor, buckets, adapters for 15 and 50 mL tubes and bio-containment lids. Many a-la-carte options are also available, contact us for more details.
PACKAGE CONTENTS
(1) Centrifuge, (1) Horizontal Rotor, (4) Buckets, (4) Adapters 15 mL, (4) Adapters 50 mL, (4) Bio-containment lids
| TUBE QTY. | VOLUME (mL) | SIZE (mm) | RPM | RCF |
| 8 | 15 Conical | 17 x 120 | ≤ 4,500 | ≤ 3,328 |
| 4 | 50 Conical | 29 x 115 | ≤ 4,500 | ≤ 3,328 |
UNIVERSAL 320 / 320R – CELL CULTURE PACKAGE – 8
4170-10-0225 | 4170-10-0235
The UNIVERSAL 320 Cell Culture Package 8 comes complete with everything you need to perform your application. This includes the UNIVERSAL 320 or UNIVERSAL 320 R centrifuge, swing-out rotor, buckets and adapters for 15 and 50 mL tubes. Many a-la-carte options are also available, contact us for more details.
PACKAGE CONTENTS
(1) Centrifuge, (1) Horizontal Rotor, (4) Buckets, (8) Adapters 15 mL, (8) Adapters 50 mL
| TUBE QTY. | VOLUME (mL) | SIZE (mm) | RPM | RCF |
| 8 | 15 Conical | 17 x 120 | ≤ 4,500 | ≤ 3,260 |
| 8 | 50 Conical | 29 x 115 | ≤ 4,500 | ≤ 3,260 |
UNIVERSAL 320 / 320R – PLATE PACKAGE
4170-10-0061 | 4170-10-0064
The UNIVERSAL 320 Plate Package comes complete with everything you need to perform your application. This includes the UNIVERSAL 320 or UNIVERSAL 320 R centrifuge, swing-out rotor and buckets. Many a-la-carte options are also available, contact us for more details.
PACKAGE CONTENTS
(1) Centrifuge, (1) Horizontal Rotor, (2) Buckets
| PLATE QTY. | VOLUME (mL) | SIZE (mm) | RPM | RCF |
| 10 | Microtiter | — | ≤ 4,000 | ≤ 2,218 |
| Weight | 1600 oz |
|---|---|
| Dimensions | 40 × 48 × 48 in |
| Rotor Package | NO ROTOR, CONICAL TUBE PACKAGE, BLOOD TUBE PACKAGE, BLOOD TUBE 4 – BC PACKAGE, URINALYSIS PACKAGE, CELL CULTURE – 4 PACKAGE, CELL CULTURE 4 – BC PACKAGE, CELL CULTURE – 8 PACKAGE, PLATE PACKAGE |
